    2000x6000mm 7.5KW UT2060A Woodworking CNC Router Machine

    Ask Lasest Price
    Brand Name : Unitec
    Model Number : UT2060A
    Certification : ce
    Price : Negotiable
    Payment Terms : T/T, L/C, Western Union
    Delivery Time : 10-15 working days
    • Product Details
    • Company Profile

    2000x6000mm 7.5KW UT2060A Woodworking CNC Router Machine

    UT2060A CNC Router machine 2060 large working size CNC Router 2000x6000mm long table woodworking machine​


    Feature of cnc router 2060:

    • Ball screw for Z axis,it's stable running and precision.
    • X Y axis are gear rack,it's stable running,precision and fast.
    • Syntec control system easy to learn operate and more precision.
    • This atc wood cnc router designed with inline type auto tool changer.Difference tool can be installed in tool holder.Spindle working one by one,more convenient to change the tool,high efficiency and save time.
    • Heavy duty frame and gantry,it's very strong and stability.

    Applications and Materials


    • Furniture Industry: wood doorcabinetclassic furniturepanel furnitureetc
    • Woodworking Industry: Automotive TrimStereo EquipmentInstrumentsOffice FurnitureCloset,etc
    • PVC Crafts Industry: solid woodartificial stonemarblesandstonealuminum composite panelbamboosoft metalPVCacrylicdouble color board, etc

    Technical parameters


    XYZ Travel Size

    2050X6050X200mm

    Max Working Size

    2000X6000X150mm
    Table Size2050X6000mm
    Transmission TypeXY/Z XY rack/Z ball screw
    Guide RailLinear Guide
    Table Typevacuum
    Vacuum Pump7.5KW/4.8KW 7.5KW water recycle cool pump or 4.8KW air pump
    Spindle Power6KW/5.6EL China air cool spindle or 5.6KW Italy Air cool spindle
    Spindle Speed18000rpm

    Max Travel Speed

    30000mm/min
    Max Work Speed20000mm/min
    Motorservo motor
    Work VoltageAC380V 50HZ
    Controller SystemNcstudio

    Processing Accuracy

    0.05mm

    Repeat Positioning Accuracy

    0.01mm
    File FormatG/PLT G code or PLT
    Overall Weight3500KG
    Overall Dimension2500X6600X1900mm

    • Integral welded Frame, mounting surface of guide ail and rack processed by high-precision milling machine, ensure the machine running stability
    • Various of table styles makes convenient clamping materials and improves overall production efficiency
    • Smooth bottom surface, clear edge contour and fine processing quality.
    • Main configurations adopts imported accessories which will ensure the overall running performance
    • CE Strict compliance with CE electrical standards for circuit design and production, and all
    • Parts have safe and reliable protection device.

    Certificate

    • CE certificated for European countries

    • CCVO SONCAP certificated for Nigeria customers

    • FTA certificate for Pakistan customers

    • SASO certificate for Saudi Arabic customers

    • Form E certificate for Indonesia and Vietname customers

    Packaging & Delivery

    Packaging Details:

    • Outside package: Standard marine export plywood case.
    • Inner package: Three layers in total; EPE pearl cotton film+PE stretchy film.

    Improved package, much more strong and environmental protection.

    We can also make package according to your requests.


    Delivery Detail: Shipped in 25-30 working days after payment
