Brand Name : | Unitec |
Model Number : | UT900 |
Certification : | CE |
UT900 600 X 900 CNC Engraving Machine Stepper Motor
MODEL | UT-6090 |
Working Area (X*Y*Z) | 600X900X150mm |
Processing accuracy | 0.01mm |
Repositioning accuracy | 0.05mm |
Spindle | 1.5KW variable speed, water-cooled |
Spindle rotating speed | 24000RPM |
Max Moving Speed | 8000MM/MIN |
Working speed | 6000MM/MIN |
Guideway | linear guideway/cylindrical guideway |
Driving mode | ballscrew |
Voltage | AC 220/50 /60 Hz (or 110v/60HZ) |
Max. Power consumption | 1.9kw |
Feeding Height | 150mm |
Drive motor | stepper motor |
Command | G.code , mmg , plt , uoo,HPGL |
Controlling system | Ncstudio(optional:MACH3 or DSP) |
Compatible Software | Artcam/Type3/Mastercam |
Certificate | CE |
Pack dimensions |
|
Net weight |
|
APPLICABLE MATERIALS
Wood, acrylic, PVC, density boards, artificial stones, organic glass, plastics and soft metal sheets such as copper and aluminum.
![]() |
